Echoblaster128 (EchoB)

Discontinued. See Micro for modern equivalent

Key Features:

  • Portable: 62 x 210 x 165mm ; 1.6kg
  • Hardware sync signal: TTL pulse on completion of every frame allowing fully automated, accurate audio sync.
  • Speech capture software: Integrated with AAA capture/analysis software
  • Raw scan data capture: Saves disk space and allows more accurate analysis. No torn images.
  • Microconvex probe 5-8MHz probe recommended for imaging children and small to medium sized adults
  • High frame rate: Frame rate up to 120Hz (more typically 87Hz for 70mm depth; 70% FOV)
  • Low Cost
  • No fan noise There is no cooling fan so microphone can be near machine.
  • Low frequency probe option 2-4MHz convex probe for better penetration when imaging larger adults
  • Good image quality 128 echo beams per full scan mean Image detail compares well with top end systems.

EchoB 2 probes
